Smart CO2 Controller Dual Channel NDIR CO2 Sensor Day Night Carbon Dioxide Detector 0-5000PPM for Greenhouse Hydroponics Smart CO2 Controller Dual Channel NDIR Sensor Monitor 0 to 5000ppm provides accurate monitoring and control of carbon dioxide levels for greenhouse and hydroponic environments. Equipped with a dual-channel low-drift NDIR sensor and a 4.6-meter remote cable, this system offers reliable readings and convenient installation. With a built-in day/night photo sensor, real-time display, and simple operation, it supports consistent environmental monitoring without the need for initial calibration.
Specifications Measurement Range: 0 to 5000 ppm Accuracy (0 to 3000 ppm): ±50 ppm or ±5% of reading Accuracy (>3000 ppm): ±7% Display Resolution: 1 ppm (0 to 1000), 5 ppm (1000 to 2000), 10 ppm (>2000) Response Time: <2 min (63%), <4.6 min (90%) Warm-Up Time: <30 sec Power Input: AC 100 to 240 VAC
Response Time: <2 min (63%), <4.6 min (90%)
Warm-Up Time: <30 sec
Power Input: AC 100–240 VAC
Operating Temperature: 32–122°F (0–50°C)
Storage Temperature: -4–140°F (-20–60°C)
Operating & Storage Humidity: 0–95% (non-condensing)
Sensor Cable Length: 4.6 meters
Sensor Unit Dimensions: 153 × 33 × 27 mm (6.0 × 1.3 × 1.1 in)
Control Unit Dimensions: 195 × 145 × 44 mm (7.7 × 5.7 × 1.7 in)
Package Weight: 1293 g
Gas Type: CO2
Display: LCD Screen
Certification: CE
Battery Included: No
Smart Device: No
Features
-
Dual Channel NDIR Sensor: Provides stable and accurate CO2 measurement with low drift performance.
-
Day/Night Sensor: Built-in photo-cell adjusts operation based on lighting conditions.
-
Real-Time Monitoring: Displays ambient CO2, set center value, and zone value on screen.
-
Remote Sensor Design: Split-type sensor with 4.6-meter cable for flexible placement.
-
Ready to Use: No initial setup or calibration required.
-
MAX/MIN Display: Tracks and displays maximum and minimum readings.
-
Chart Display: Includes variable time zoom levels for data visualization.
Package Contents
-
Included: 1 x CO2 Controller Unit
-
Included: 4 x Screws
-
Included: English User Manual
-
Included: Standard Packaging
